Wilwood Compact Combination Master Cylinder with 3/8-24 Banjo Outlet – 1 Inch Bore

‘This new version of Wilwood's Compact Combination Master Cylinders now features a 3/8-24 banjo outlet. Designed for limited space applications requiring the output capacity of a full size master cylinder. The ultra-short 3.37”compact body provides 2.16” of additional clearance between the mounting flange and the fluid outlet. A full 1.12” of piston stroke meets or exceeds the stroke capacity of most full size cylinders. With 3/8-24 fluid outlet port located at the top radius of the cylinder bore, reduces the chances for trapped air. Enhanced fluid inlet port allows mounting of the standard reservoir included in kit and also contains 11/16-20 internal threads for custom reservoir arrangements. The black E-Coated aluminum body resists corrosion and maintains a durable long lasting finish.

The Wilwood Short Remote Master Cylinder (Part Number 260-13622) is engineered for limited space applications that demand high performance and reliability. Featuring a compact body measuring just over 3.3 inches in length, this master cylinder provides an additional 2.16 inches of clearance between the mounting flange and the fluid outlet, making it ideal for tight engine bays or custom builds. Its 1-inch bore diameter ensures consistent brake pedal feel and effective fluid transfer, meeting or exceeding the stroke capacity of many full-size cylinders. The integrated 3/8-24 banjo outlet positioned at the top radius of the bore minimizes trapped air, promoting more efficient bleeding and consistent brake response.

Constructed from durable aluminum with a corrosion-resistant black E-coating, this master cylinder offers long-lasting performance in demanding automotive environments. The enhanced fluid inlet port accommodates the included standard reservoir and features 11/16-20 internal threads, allowing for customized reservoir configurations. Its versatile design ensures compatibility with a variety of brake systems, making it suitable for performance vehicles, race applications, or custom builds where space is at a premium.

Overall, the Wilwood Short Remote Master Cylinder combines compact design, high capacity stroke, and corrosion resistance to deliver reliable and efficient brake performance. Whether upgrading an existing system or designing a new custom setup, this master cylinder provides a dependable solution tailored for limited space constraints without compromising on brake feel or fluid capacity.

Features:

• Compact design with a body length of approximately 3.37 inches for tight installation spaces

• 1-inch piston bore for optimal brake pedal feel and fluid transfer

• 3/8-24 banjo outlet positioned at the top radius to reduce trapped air

• Enhanced fluid inlet port compatible with standard reservoir and custom reservoir options

• Durable black E-coated aluminum body resists corrosion and ensures longevity

• Additional 2.16 inches of clearance between flange and outlet for easier installation

Air Freight Prohibited: false
Not Carb Approved: false
Ltl Freight Required: false
Prop 65: Unknown
Part Type: automotive
Epa: N/A
Carb Acknowledgement Required: false
Regular Stock: t
Units Per Sku: 1
