Wilwood Compact Combination Master Cylinder Kit 7/8 Inch Bore – Part Number 260-10374

Wilwood’s Compact Combination Master Cylinders have been designed for limited space applications requiring the output capacity of a full size master cylinder. The ultra short 3.37”compact body provides 2.16” of additional clearance between the mounting flange and the fluid outlet. A full 1.12” of piston stroke meets or exceeds the stroke capacity of most full size cylinders. With 1/8” NPT fluid outlet port located at the top radius of the cylinder bore, reduces the chances for trapped air. Enhanced fluid inlet port allows mounting of the standard reservoir included in kit and also contain 11/16-20 internal threads for custom reservoir arrangements. The black E-Coated aluminum body resists corrosion and maintains a durable long lasting finish.

The Wilwood Compact Combination Master Cylinder Kit offers a space-efficient solution for automotive applications requiring full-size output capacity. Its ultra-short 3.37-inch body provides an additional 2.16 inches of clearance between the mounting flange and fluid outlet, making it ideal for tight engine bays or custom builds. The master cylinder features a piston stroke of 1.12 inches, ensuring reliable operation and compatibility with most full-size cylinders. Its design includes a top-mounted 1/8-inch NPT fluid outlet port, which minimizes trapped air and promotes consistent brake feel. The fluid inlet port is enhanced for mounting the standard reservoir included in the kit, and it contains 11/16-20 internal threads suitable for custom reservoir configurations. The black E-coated aluminum body offers excellent corrosion resistance and durability, maintaining a long-lasting finish even in demanding environments. This master cylinder is suitable for various automotive braking systems, providing a compact yet powerful component for custom or limited space installations. Its robust construction and thoughtful design ensure reliable performance, making it an excellent choice for performance vehicles, hot rods, and racing applications requiring a compact master cylinder without sacrificing capacity or stroke length.

Features:

• Ultra-compact 3.37-inch body provides additional clearance for limited space applications

• Full 1.12-inch piston stroke meets or exceeds most full-size cylinders

• Top-mounted 1/8-inch NPT fluid outlet port reduces trapped air

• Enhanced fluid inlet port supports standard reservoir and custom reservoir options

• Black E-coated aluminum body resists corrosion for long-lasting durability
